Gore PhaseFlex pn ver.11
Gore
18914031336
1931048209
0512-68050516
戈尔(GORE)
可销售
| P/N | 频率 | 基线 | 相位稳定性（典型值） | 弯曲次数 | 适配接插件 |
| 0S | 18GHz | 0.190 (Stranded) | ±2.0° | 100,000 | N,SMA,TNC 7/16,3.5mm |
| 0H | 18GHz | 0.120 (Stranded) | ±2.0° | 100,000 | SMA |
| 0W | 26.5GHz | 0.190 (Solid) | ±3.0° | 50,000 | 3.5mm |
| 0K | 40GHz | 0.140 (Solid) | ±5.0° | 50,000 | 2.92mm, 2.4mm |
| 0Z | 50GHz | 0.140 (Solid) | ±6.0° | 20,000 | 2.4mm, 2.92mm |
| 0F | 67GHz | 0.089 (Solid) | ±8.0° | 20,000 | 1.85mm |
| P/N | 频率 | 基线 | 相位稳定性（典型值） | 弯曲次数 | 适配接插件 |
| 0S | 18GHz | 0.190 (Stranded) | ±2.0° | 100,000 | N,SMA,TNC 7/16,3.5mm |
| 0H | 18GHz | 0.120 (Stranded) | ±2.0° | 100,000 | SMA |
| 0W | 26.5GHz | 0.190 (Solid) | ±3.0° | 50,000 | 3.5mm |
| 0K | 40GHz | 0.140 (Solid) | ±5.0° | 50,000 | 2.92mm, 2.4mm |
| 0Z | 50GHz | 0.140 (Solid) | ±6.0° | 20,000 | 2.4mm, 2.92mm |
| 0F | 67GHz | 0.089 (Solid) | ±8.0° | 20,000 | 1.85mm |
