重量: 8kg
带宽 500 MHz
通道数量 4 ch
Simultaneous Channels 4 ch
Simultaneous Maximum Sampling Rate/ch 500 MSa/s
One ch. only max. sampling rate 500 MSa/s
Max. Record Length 250000 pt/sec
Min. Vertical Sensitivity 2 mV/div
Maximum Vertical Sensitivity 10 V/div
Number of Bits 8 bits
Input Impedance 1 MOhm
Input Impedance (alternate) 50 Ohm
Input Coupling AC,DC,GND
Maximum Input Voltage 400 Vrms
Maximum Input#2 (for Impedance #2) 5 Vrms
Main time base - lowest 1 ns/div
Main time base - highest 1000 s/div
时基精度 0.001 %
触发源 CH1,CH2,CH3,CH4,External
触发模式 Auto,Coupling,Level,Normal,Single,Slope,Stop
显示屏 液晶屏
显示屏尺寸 21.336 cm
显示模式 Auto,Normal,Single,Stop
